GraphQl with Spring Boot 3

What's GraphQl and some key points of it?

GraphQL is a query language for APIs that allows clients to request exactly the data they need and receive predictable results. Here are some key points about GraphQL:

• Data Description: GraphQL provides a complete and understandable description of the data in your API. It defines types, fields, and relationships between them.
• Precise Queries: Clients can ask for specific data by sending GraphQL queries. Unlike traditional REST APIs, where endpoints return fixed data structures, GraphQL queries return only the requested fields.
• Single Request: GraphQL queries can access multiple resources in a single request. This efficiency is especially useful for mobile apps on slow networks.
• Type System: GraphQL APIs are organized around types and fields. Types ensure that clients ask for valid data and receive clear error messages.
• Developer Tools: GraphQL makes it easy to build tools like GraphiQL, which helps developers explore and test APIs.

Advantages and Disadvantages

Certainly! Spring Boot provides a convenient way to build GraphQL APIs. Here’s how you can set up a GraphQL server using Spring Boot:

• Dependencies:
  • Add the graphql-spring-boot-starter dependency to your Spring Boot project. This starter includes the necessary components for GraphQL.
  • You can also use libraries like SPQR or graphql-java-kickstart for additional features12.
• Schema Definition:

  • Define your GraphQL schema. This schema describes the types, queries, and mutations available in your API.
  • Specify the types (e.g., Post, Author) and their fields (e.g., id, title) in your schema1.
• Controller Mapping:

  • Create a controller class with @Controller annotation.
  • Use @QueryMapping and @MutationMapping to map GraphQL queries and mutations to methods that interact with your data repositories (e.g.,
  • JPA repositories for database access)3.
• GraphiQL Console:

  • Enable the GraphiQL console in your application properties. GraphiQL is a web-based tool for testing GraphQL queries and exploring your API.
  • Use it to test your GraphQL API with different queries and mutations3.
• Testing and Optimization:

  • Write unit tests for your GraphQL queries and mutations.
  • Be aware of potential performance issues, such as the N+1 problem when fetching lazy collections of related data (e.g., authors and their posts).
  • Consider using Query DSL to optimize data retrieval34.

Code

Using dependencies such as below:

<dependencies>
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-data-jpa</artifactId>
		</dependency>
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-web</artifactId>
		</dependency>
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-graphql</artifactId>
		</dependency>
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-validation</artifactId>
		</dependency>

		<dependency>
			<groupId>org.postgresql</groupId>
			<artifactId>postgresql</artifactId>
			<scope>runtime</scope>
		</dependency>
		<dependency>
			<groupId>com.h2database</groupId>
			<artifactId>h2</artifactId>
			<scope>runtime</scope>
		</dependency>
		<dependency>
			<groupId>org.mapstruct</groupId>
			<artifactId>mapstruct</artifactId>
			<version>${org.mapstruct.version}</version>
		</dependency>
		<dependency>
			<groupId>org.projectlombok</groupId>
			<artifactId>lombok</artifactId>
			<version>${org.projectlombok.version}</version>
			<optional>true</optional>
		</dependency>
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-test</artifactId>
			<scope>test</scope>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-webflux</artifactId>
			<scope>test</scope>
		</dependency>
		<dependency>
			<groupId>org.springframework.graphql</groupId>
			<artifactId>spring-graphql-test</artifactId>
			<scope>test</scope>
		</dependency>
	</dependencies>

add below config to application.properties for allow graphql

spring.graphql.graphiql.enabled=true

add graphql's schema to package: "/resources/graphql/schema.student" with mutation and query such as below:

• Mutation for student with name: mutation.students.graphqls

type Mutation{
    createStudent(createStudentDTO : CreateStudentDTO):StudentDTO
    updateStudent(studentId:Float!, updateStudentDTO : UpdateStudentDTO):StudentDTO
    deleteStudent(studentId:Float!):String
}

input CreateStudentDTO{
    firstName: String
    lastName: String
    age: Int
    isDeleted: Boolean
    courses: [Float!]
}

input UpdateStudentDTO{
    id: Float
    firstName: String
    lastName: String
    age: Int
    isDeleted: Boolean
    courses: [Float!]
}

• Query schema with name: query.students.graphqls

type Query {
    allStudents(paginationReq: PaginationReq!) :StudentContent
    getStudents(studentId: Float!) :StudentDTO
}

type StudentContent {
    pagination: Pagination
    content:[StudentDTO]
}
input PaginationReq {
    page: Int
    size: Int
}
type StudentDTO {
    id:Float
    firstName:String
    lastName:String
    age:Int
    isDeleted:Boolean
    courses:[CourseDTO]
}
type Pagination {
    page: Int
    size: Int
    totalPage: Float
    totalElement: Float
}

type CourseDTO {
    id:Float
    name:String
}

Create controller to handle request from user with graphql such as annotation:

• @QueryMapping: using for bind this method to a query, i.e. a field under the Query type.
• @MutationMapping: to associate the method with a mutation field in your GraphQL schema.
• @Argument: for access to a named field argument bound to a higher-level, typed Object.

package com.tra21.graphqltesting.controllers;

import com.tra21.graphqltesting.payloads.dtos.students.CreateStudentDTO;
import com.tra21.graphqltesting.payloads.dtos.students.StudentDTO;
import com.tra21.graphqltesting.payloads.dtos.students.UpdateStudentDTO;
import com.tra21.graphqltesting.payloads.req.PaginationReq;
import com.tra21.graphqltesting.payloads.res.students.StudentContents;
import com.tra21.graphqltesting.services.students.IStudentService;
import lombok.RequiredArgsConstructor;
import org.springframework.graphql.data.method.annotation.Argument;
import org.springframework.graphql.data.method.annotation.MutationMapping;
import org.springframework.graphql.data.method.annotation.QueryMapping;
import org.springframework.stereotype.Controller;

@Controller
@RequiredArgsConstructor
public class StudentController {
    private final IStudentService studentService;
    @QueryMapping
    public StudentDTO getStudents(@Argument Long studentId ) {
        return studentService.getStudents(studentId);
    }
    @QueryMapping
    public StudentContents allStudents(@Argument PaginationReq paginationReq) {
        return studentService.allStudents(paginationReq);
    }
    @MutationMapping
    public StudentDTO createStudent(@Argument CreateStudentDTO createStudentDTO){
        return studentService.createStudent(createStudentDTO);
    }
    @MutationMapping
    public StudentDTO updateStudent(@Argument Long studentId, @Argument UpdateStudentDTO updateStudentDTO){
        return studentService.updateStudent(studentId, updateStudentDTO);
    }
    @MutationMapping
    public String deleteStudent(@Argument Long studentId){
        return studentService.deleteStudent(studentId) ? "Success deleted student." : "Failed to delete student.";
    }
}

Create CustomErrorResolver for handle error

package com.tra21.graphqltesting.exception;

import graphql.ErrorClassification;
import graphql.GraphQLError;
import graphql.GraphqlErrorBuilder;
import graphql.schema.DataFetchingEnvironment;
import jakarta.validation.ConstraintViolation;
import jakarta.validation.ConstraintViolationException;
import org.springframework.core.NestedExceptionUtils;
import org.springframework.graphql.execution.DataFetcherExceptionResolverAdapter;
import org.springframework.http.HttpStatus;
import org.springframework.stereotype.Component;

import java.util.stream.Collectors;
@Component
public class CustomErrorResolver extends DataFetcherExceptionResolverAdapter {
    @Override
    protected GraphQLError resolveToSingleError(Throwable ex, DataFetchingEnvironment env) {
        Throwable t = NestedExceptionUtils.getMostSpecificCause(ex);

        if(t instanceof ConstraintViolationException constraintViolationException){
            return validationError(constraintViolationException, env);
        }else if (t instanceof NotFoundException exception) {
            return GraphqlErrorBuilder.newError(env)
                    .errorType(ErrorClassification.errorClassification(HttpStatus.BAD_REQUEST.name()))
                    .message(exception.getMessage())
                    .build();
        }else if (t instanceof RuntimeException exception) {
            return GraphqlErrorBuilder.newError(env)
                    .errorType(ErrorClassification.errorClassification(HttpStatus.INTERNAL_SERVER_ERROR.name()))
                    .message("Unexpected Error!")
                    .build();
        }

        // other exceptions not yet caught
        return GraphqlErrorBuilder.newError(env)
                .message("Error occurred: Ensure request is valid ")
                .errorType(ErrorClassification.errorClassification(HttpStatus.INTERNAL_SERVER_ERROR.name()))
                .build();
    }

    private GraphQLError validationError(ConstraintViolationException exception, DataFetchingEnvironment env){
        String invalidFields = exception.getConstraintViolations().stream()
                .map(ConstraintViolation::getMessage)
                .collect(Collectors.joining("\n"));

        return GraphqlErrorBuilder.newError(env)
                .errorType(ErrorClassification.errorClassification(HttpStatus.INTERNAL_SERVER_ERROR.name()))
                .message(invalidFields)
                .build();
    }
}

Summary

Download the source code for the sample application with graphql. After this tutorial you will learn such as:

• Spring Framework
• SpringBoot
• Spring Data Jpa
• H2 database
• Graphql
• Lombok
• Mapstruct
